INSIZE 3128-10 Digital Wide Range Three Points Internal Micrometer, 6-10"/152-254mm
by Insize
$5,442.00
INSIZE 3128-10 Digital Wide Range Three Points Internal Micrometer
Are you looking for a high-precision digital three-point internal micrometer, designed for reliably measuring large bores over a wide range? The INSIZE 3128-10 is built to perform in workshop and industrial environments, this tool offers great accuracy, repeatability, and ease of use perfect for quality control, engineering, and machining applications.
Key Features
- Wide Measuring Range: Covers internal diameters from 6″ to 10″ (152 mm – 254 mm), giving you flexibility to measure a broad range of bore sizes.
- High Resolution: Digital readout supports a resolution of 0.00005″ (0.001 mm).
- Rugged and Durable: Rated IP54 for dust and splash resistance, ensuring reliable performance in shop environments.
- User-Friendly Controls: Dedicated buttons for on/off, set, inch/mm, and ABS/INC modes make it easy to use and switch between settings.
- Data Output: Equipped with digital data output for SPC (statistical process control) or other recording systems, enabling seamless integration into data collection workflows.
- Automatic Power Off: Conserves battery life by powering down after inactivity.
- Measuring Faces: Uses carbide measuring faces for durability, wear resistance, and consistent accuracy over time.
- Ratchet Stop: Provides a consistent measuring force to improve repeatability and prevent over-torque that could distort the measurement.
- Complies with Standards: Designed to meet DIN 863-4 for internal micrometers.
Specifications
| Measuring Range | 6″ – 10″ (152 mm – 254 mm) |
| Resolution | 0.00005″ / 0.001 mm |
| Accuracy | ±0.00032″ |
| IP Rating | IP54 (dust / splash-proof) |
| Power Supply | LR44 (or SR44) battery |
| Power Management | Automatic power off |
| Measuring Faces Material | Carbide |
| Stop / Lock Type | Ratchet stop |
| Output | Data output (SPC compatible) |
| Optional Accessories | Data output cable (INSIZE codes: 7315-30, 7302-30) |
Items Included
- The digital micrometer head (6–10″ range)
- A 6″ diameter setting ring (used for calibration)
- Extension rods (these help reach deeper bores)
- LR44 battery
- Plastic storage / carrying case
- Inspection / calibration certificate traceable to a quality standard (INSIZE provides traceable certs)
Insize 3128-10 Digital Wide Range Three Points Internal Micrometer Manual
