- Designed primarily for lifting round or curved parts, such as pipes, shafts, and billets.
- On/off rare-earth magnet with 90° rotating handle that locks securely in both positions.
Mag-Mate Flaig FXR Round Part Lift Magnet
by Mag-Mate
$1,151.54
Mag-Mate Flaig FXR Round Part Lift Magnet
Are you looking for a purpose-built for lifting curved and cylindrical steel surfaces like shafts, billets, and round pipes while still retaining the ability to lift flat steel when needed? The Mag‑Mate FXR Round Part Lift Magnet series are rare-earth, on/off permanent magnets deliver dependable, deep-penetrating magnetic hold thanks to their specially contoured pole shoes. With handle lock-on/off, a compact design, and a 3:1 safety factor, the FXR models make for a safe, efficient, and practical lifting solution in fabrication, machine shops, and warehouse environments.
Key Features
- Designed primarily for lifting round or curved parts, such as pipes, shafts, and billets.
- On/off rare-earth magnet with 90° rotating handle that locks securely in both positions.
- Deep-penetrating pole shoes create a stable magnetic field, enhancing grip on cylindrical surfaces.
- Corrosion-resistant plated surface keeps the magnet durable in tough shop environments.
- Heat resistance up to 180°F (82°C) for performance in moderately hot industrial settings.
- Safety-rated 3:1 design factor, compliant with ASME B30.20 / BTH-1 standards.
Specifications
| Model | Working Load Limit (WLL) | Overall Length | Handle Length | Weight |
| Mag‑Mate FXR0500 | 500 lb | 8.00 in | 7.5 in | 21 lb |
| Mag‑Mate FXR1000 | 1,000 lb | 11.3 in | 9.0 in | 49 lb |
| Mag‑Mate FXR1650 | 1,650 lb | 14.2 in | 10.2 in | 108 lb |
| Mag‑Mate FXR2650 | 2,650 lb | 18.5 in | 16.1 in | 280 lb |
| Mag‑Mate FXR4000 | 4,000 lb | 25.5 in | 21 in | 402 lb |
Items Included
- The FXR lifting magnet itself
- 90° rotatable locking handle (on/off)
- Integral swivel lift bail (for crane or hoist)
- Test certificate or load-test documentation
- User manual and safety instructions
Mag-Mate FXR0500 Flaig FXR Magnet CAD Drawing
Mag-Mate FXR1000 Flaig FXR Magnet CAD Drawing
Mag-Mate FXR1650 Flaig FXR Magnet CAD Drawing
